MF Series Centrifugal Atomization Misting Fan
MODEL SERIES: MF-01 (Stand) / MF-02 (Wall)
The MF Series Centrifugal Misting Fan utilizes high-speed centrifugal disc atomization rather than micro-nozzles, completely eliminating nozzle clogging issues from hard water or sediment. It generates an ultra-fine water fog that evaporates instantly, dropping ambient temperatures by 4°C to 8°C.
Technical Specifications
Blade Size 650mm / 750mm (26" / 30")
Mist Droplet Size < 20 Microns (Instant Evaporation)
Water Tank Capacity 42 Liters (Stand Model)
Mist Volume Control Adjustable Mist Output Valve
Cooling Area 50 m² - 80 m²
Temperature Drop 4°C - 8°C Instant Cooling
Engineering Highlights
- Centrifugal disc atomization technology with 100% clog-free performance
- Instant ambient temperature reduction of 4°C to 8°C via flash evaporative cooling
- Suppresses airborne dust, pollen, odors, and static electricity
- Stand model includes 42L integrated water tank with heavy-duty rolling casters
Recommended Applications
- Outdoor Restaurants, Cafes & Theme Parks
- Foundries, Forges, Glass & Rubber Workshops
- Horticultural Greenhouses & Livestock Barns
- Dust Suppression at Loading Docks & Demolition Sites
