DT Series Low-Noise Fire Smoke Exhaust Cabinet Fan
MODEL SERIES: DT / DT-Y Series (280°C Rated)
The DT Series is an acoustic cabinet-enclosed centrifugal fan certified for dual-purpose ventilation and emergency 280°C smoke evacuation. Equipped with double-inlet centrifugal wheels inside a rigid sound-absorbing cabinet.
Technical Specifications
Air Flow Capacity 2,000 - 68,000 m³/h
Static Pressure 200 - 1,100 Pa
Fire Smoke Rating 280°C / 0.5h Fire Extraction Certified
Cabinet Structure Double-Skin Acoustic Insulated Panel Frame
Motor Location External Motor Compartment (Belt Drive)
Engineering Highlights
- Certified to operate continuously at 280°C for over 30 minutes in fire emergencies
- Double-skin acoustic panels providing exceptional sound attenuation
- Motor located outside the airstream protected from grease, heat, and smoke
- Removable side panels for easy on-site inspection and belt servicing
Recommended Applications
- Underground Parking Garage Ventilation & Smoke Evacuation
- Commercial Shopping Mall Fire Protection Systems
- Hotel & Hospital HVAC Central Supply/Exhaust
