Official Technical Catalogue
PDF 2025 Download complete PDF with full curves and dimensions.
CDF Series Circular In-Line Duct Fan
MODEL SERIES: CDF12-35E / CDF16-45E / CDF31-66E / CDF16-45A / CDF20-66A / CDF25-80A / CDF31-90A
The CDF Series circular in-line duct fan combines external rotor motor technology with backward-curved centrifugal impellers in a compact round metal casing. Engineered for high static pressure duct booster systems.
Technical Specifications
Duct Diameter 100mm - 315mm (4" - 12")
Air Volume 250 - 2,100 m³/h
Static Pressure 280 - 750 Pa
Motor Type External Rotor Motor (IP44 / Class B/F)
Casing Material Epoxy Powder-Coated Pressed Galvanized Steel
Speed Control 100% Voltage Controllable
Engineering Highlights
- Compact in-line circular configuration allowing direct mounting in straight duct runs
- High static pressure capability overcoming extensive flex-duct runs and carbon filters
- Maintenance-free sealed ball bearings rated for 40,000+ continuous hours
- Airtight casing design preventing duct air leakage
Recommended Applications
- Apartment, Hotel & Office HVAC Boosters
- Bathroom, Restroom & Kitchen Exhaust Systems
- Hydroponic & Indoor Grow Room Carbon Filtration
- Cleanroom & Laboratory Air Transfer
